10' x 7.4' SEGO Modular Lightbox Display Configuration E Double-Sided

A three-sided lit booth rather than a flat wall. Configuration E is a 10 ft. SEGO back wall with a return panel turning forward on each side, so the display encloses the booth space and reads from the aisle at an angle instead of only head-on. Assembled it is 118 in. wide and 43.75 in. deep, and every face carries a backlit graphic.

The LEDs are pre-installed inside the aluminum extrusions, and magnetic electrical connectors carry power across the joints as the sections lock together. Nothing is wired by hand on the show floor and no cabling shows.

Key Features

• Back wall plus two returns: The side panels turn forward to define the booth, which keeps attendees inside your footprint instead of walking past the edge of a flat wall.

• LEDs built into the frame: UL-certified LED strips come pre-installed in the profiles. Magnetic connectors pass power between sections, so the wiring stays inside the aluminum.

• Tool-free, down to the feet: Frames, connectors and feet assemble without tools or fasteners.

• Borderless SEG graphics: Silicone beading sewn into the fabric edge tucks into the frame channel, so the graphic pulls flat and the aluminum disappears behind it.

• Reconfigurable: The panels are modular. The same frames rebuild into flat 10 ft. or wider SEGO layouts when the booth size changes.

• Foam-cut travel bags: Each section ships in a bag with cut foam holding the frame, graphic and electrical parts in their own places.

Specifications

• Assembled size: 118 in. W x 88.25 in. H x 43.75 in. D
• Back wall graphic: 118.625 in. W x 88.625 in. H
• Layout: one back wall with two forward-turning side returns
• Sides printed: double-sided
• Frame: aluminum extrusion, tool-free, LED strips pre-installed
• Electrical: magnetic connectors between sections, standard outlet
• Graphic material: dye-sublimated backlit SEG fabric with silicone edge
• Back wall cartons: four, 54.5 in. x 15.5 in. x 6.75 in., about 60 lbs each
• Return cartons: two, 45.5 in. x 15.5 in. x 6.75 in., about 23 lbs each
• Total shipped: six cartons, roughly 285 lbs
• Setup: two people, tool-free; sections lock together and the feet slip on

What's Included

• Backlit dye-sublimated SEG fabric graphics for the back wall and both returns
• Horizontal top and bottom profiles, vertical profiles and mid poles with LEDs pre-installed
• (2) inside L-connectors and (1) cross connector for the returns
• (6) feet
• (1) LED connector, (3) transformers and (3) Y cables
• (3) foam-cut travel bags

Shipping

Shipping on this display is quoted at checkout. It goes out as six cartons — four back wall boxes of 54.5 x 15.5 x 6.75 in. at about 60 lbs, and two return boxes of 45.5 x 15.5 x 6.75 in. at about 23 lbs.

Where a three-sided lit booth fits

This suits a 10x10 that needs to feel like a room, or the back half of a 10x20 with the front left open for a counter and traffic. At 43.75 in. deep the returns use booth depth you already paid for and give you two extra lit faces without extra floor width.

Outside the exhibit hall the same frames make lit alcoves in lobbies, showrooms, university recruiting spaces and hospital entrances, where the graphic changes with the campaign and the aluminum stays.

Ordering from Stow, Ohio

Backlit artwork behaves differently from ordinary print — light passing through the fabric flattens contrast and can wash out a dark logo or a photograph. We lay out the graphics, proof them, and say plainly when something will not read once it is lit.

For customers across Northeast Ohio — Akron, Cleveland, Canton, Kent, Hudson, Youngstown — we deliver the booth, set it up at the venue and store it between shows, then reprint graphics for the next one. Outside the region it ships in its travel bags.

Show rules vary, particularly on side-wall height and sightlines into neighboring booths. Check your show's guidelines before ordering, and if the configuration needs adjusting to meet them, email sales@dgcreativ.com and we will quote the change.

Frequently Asked Questions

Will the side returns pass my show's sightline rules?
Often, but not always — many shows limit how tall a side wall may be within the first few feet of the aisle. Read the exhibitor kit for your hall, and if the layout needs changing we will quote an adjusted configuration.

Are the lights included?
Yes, and already installed inside the frame profiles. Three transformers plug into a standard outlet. Budget for one power drop at the booth.

Can I use it as a flat 10 ft. wall at some shows?
Yes. The returns are separate modular sections. Leave them in the bags and you have a flat lit back wall; add them when the booth allows the depth.

How many people does setup take?
Two is comfortable for a wall this size. No tools are needed. Whether you are allowed to set it up yourself depends on the venue's labor rules rather than on the display.

Can I reprint just the graphics?
Yes. The frames and lighting last for years. Send new artwork and we print replacement SEG graphics to the same panel sizes.
